Extracorporeal Shock Wave Lithotripsy (ESWL) system designed for the non-invasive fragmentation of kidney, ureter and bladder stones. Depending on the configuration, the system may also be used for selected orthopedic and gastroenterological applications.
Technology
Piezoelectric shock wave technology.
Direct-focus shock wave generation.
Triple Focus therapy system.
Adjustable treatment energy according to stone size and hardness.
Optional ECG synchronization.
Technical Specifications
Maximum pulse energy (12 mm stone): 123 mJ
Peak pressure: 8–126 MPa
Penetration depth: up to 165 mm
Shock wave frequency: 30–360 shocks/min
Three selectable focal zones:
F1: 3.7 × 30 mm
F2: 4.8 × 32 mm
F3: 8.7 × 63 mm
Energy density: up to approximately 1.6 mJ/mm²
Localization System
Inline ultrasound localization.
Outline X-ray localization.
Dual Simultaneous Real-Time Localization (DSR).
Continuous stone monitoring during treatment.
Power Supply
100–240 V AC, 50/60 Hz
Power consumption: approximately 1000 VA
Physical Characteristics
Dimensions: 1000 × 700 × 1000 mm
Weight: approximately 220 kg
Water system volume: approximately 10 litres
Installation Requirements
Recommended room area: approximately 20 m²
No permanent water connection required.
Low operating costs and low power consumption.
Noise Level
Maximum 72 dB(A)
Features
Non-invasive ESWL therapy.
Many procedures can be performed without general anesthesia.
Low-pain piezoelectric shock wave technology.
No reflected shock waves, minimizing tissue trauma.
Highly precise focal zone.
Motorized ultrasound and X-ray positioning.
Compatible with various treatment tables and the WOLF-Lithoarm.
Guaranteed shock wave source lifetime of 5 million shock waves or 2 years.
Modular design allowing future system expansion.
This document was translated using Artificial Intelligence (AI). The translation has been linguistically reviewed; however, for technical documentation, verification against the manufacturer's original documentation is recommended.
